Max. lifting moment（kN.m）

519

503

490

Max. lifting capacity(kg)

28000kgs

28000kgs

28000kgs

Max. hydraulic outreach(m)

16.24

18.56

20.80

slewing angle (°)

360   continuous

360   continuous

360   continuous

Stabilizer spread(mm)

8216

8216

8216

Max. operating pressure(Mpa)

32

32

32

Recommended Pump capacity (L/min)

80

80

80

Oil tank capacity(L)

300

300

300

dead weight

6900kgs

7150kgs

7350kgs

Color

red,   yellow, green, blue, white

1.   can choose Double rotary(double pumps)

2.   can choose rear supporting outrigger. Single outrigger or double cylinders   outrigger.
