Wheelbase

4200mm

Front overhang

1260mm

Rear overhang

1890mm

Wheel track of front axle

1620mm

Wheel track of rear axle

1628mm

Chassis length

7352mm

Approach angle

34°

Departure angle

15°

Maximum driving speed

88 km/h

Maximum gradeability

28%~35%

Minimum ground clearance

380mm

Minimum turning diameter

＜16.5m

Fuel consumption

26~28(L/km)

Cargo body size

5200mm×2050mm×550mm

Overall Dimension

7420mm×2300mm×2750mm

width of the cabin

1880mm

Weight

Kerb.mass

5400kg

Gross vehicle weight

11500kg

Front axle loading capacity

2500kg

Rear axle loading capacity

9000kg

  Engine   Parameters

Engine Model

YC4D130-33

Rated Power

95/2800 (KW/rmp)

Maximum Torque

380/1400~1700 (Nm/rmp)

Features

4-cylinder in-line,4.214 liter

Clutch

350 diaphragm spring clutch, single plate

Gearbox

Gearbox Type

SC8T50C 8 speed manual control

Gearbox ratio

1

10.48

2

6.46

3

4.43

4

3.11

5

2.43

6

1.49

7

1

8

0.72

R1

8.98

R2

2.07

Braking System

Type

Air brake system

Service brake

Dual-circuit air brake

Parking brake

Spring energy,Compressed air operating on rear wheels

Auxiliary brake

Exhaust valve braking(EVB)

Wheels & Tyres

Tyres

8.25R20 6+1

Wheels

7.00T-20

Steering Gear

Type

GY90

Hydraulically assisted

Axles

Steer

2080（2.5T）forging l-beam front axle

Drum brake

Drive

153AS（9.0T) central single reduction

Drum brake

2080:i=6.33

153AS:i=6.33

Fuel Tank

Capacity

150 Liters (iron )

Frame

Material

High tensile steel

Section

255*70*(8+5)mm

Frame width

800mm

Electrical System

Type

SINOTRUK CAN bus System with VCO instrument

Voltage

24V

Batteries

2x12V, 105Ah

Alternator

28V/55A

Starter

5KW

Suspension

Steer Axle

Semi-elliptical leaf springs with shock absorbers and stabilizer

Drive Axle

Semi-elliptical leaf springs
