Model

WD615.62

WD615.87

WD615.69

WD615.47

Type

4 stroke   injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling, mechanical high   pressure oil pump system

Cylinder   Valves

2

2

2

2

Bore*Stroke   (mm)

126mmx130mm

Displacement(L)

9.726L

Compression ratio(mm)

17:1

Rated   Power kW(ps)

196(266)

213(290)

247(336)

273(371)

Rated   Speed (r/min)

2200

Max.   Torque (Nm)

1100

1160

1350

1500

Speed at Max. Torque

1100-1600

Idle Speed (r/min)

600±50

Min. Specific Fuel Consumption (g/kW.h)

≤192

Net   Weight (kg)

850

850

850

850

Emission

EuroII

EuroII

EuroII

EuroII
